VertivModel: MP2-220K
Vertiv MP2-220K Microprocessor-Based DC Power System Supervisory Unit (Bus Insulation & Battery Monitoring)
The Vertiv MP2-220K is a microprocessor-based central supervisory controller designed for 220Vdc utility substations and critical power plants. It integrates full rectifier fleet management, busbar-to-ground insulation monitoring, dual AC source ATS automation, battery test profiling, and feeder ground fault location in a rugged industrial panel-mount enclosure.
Pricing is confirmed by project configuration and quantity
Request a quote- Monitored DC Bus Voltage
- 220Vdc (Sampling Accuracy ±0.2%)
- Insulation Ground Fault Detection
- Busbar & Feeder Resistance Leakage Detection
- Human-Machine Interface
- Wide-Temperature Graphic LCD with Tactile Keys
- Intelligent Battery Management
- Temperature Compensated Float/Equalize & Capacity Testing
- Substation SCADA Protocols
- RS485 / IEC 60870-5-104 / CDT / Modbus-RTU
- EMC & Enclosure Standard
- Panel Flush Mount / Level 4 Industrial EMC Compliance
What this product is
What this product is
The Vertiv MP2-220K is a microprocessor-based central supervisory controller designed for 220Vdc utility substations and critical power plants. It integrates full rectifier fleet management, busbar-to-ground insulation monitoring, dual AC source ATS automation, battery test profiling, and feeder ground fault location in a rugged industrial panel-mount enclosure.
What problem it solves
Resolves power grid instability, excessive OPEX energy dissipation, battery degradation, and rack footprint constraints.
Who and where it is for
5G cellular cell sites, core telecom DC plants, AI data centers, transport networks, and critical industrial DC UPS.
Core advantages
- Precision Insulation Monitoring: Combines DC bridge and low-frequency injection methods to locate feeder ground faults in milliseconds.
- Fleet Energy Optimization: Dynamically controls rectifier on/off states based on real-time load demand to maximize overall efficiency.
- Comprehensive Battery Diagnostics: Temperature compensation, Ah counting, and auto-equalizing routines maximize battery operational life.
- Substation SCADA Compatibility: Native support for IEC 60870-5-104, CDT, and Modbus-RTU protocols for seamless RTU integration.
Technical specifications
| Key specifications | Value |
|---|---|
| Monitored DC Bus Voltage | 220Vdc (Sampling Accuracy ±0.2%) |
| Insulation Ground Fault Detection | Busbar & Feeder Resistance Leakage Detection |
| Human-Machine Interface | Wide-Temperature Graphic LCD with Tactile Keys |
| Intelligent Battery Management | Temperature Compensated Float/Equalize & Capacity Testing |
| Substation SCADA Protocols | RS485 / IEC 60870-5-104 / CDT / Modbus-RTU |
| EMC & Enclosure Standard | Panel Flush Mount / Level 4 Industrial EMC Compliance |
Applications
01
4G/5G Telecom Cell Sites & Distributed Power Systems
02
Carrier Core Network Facilities & IDC DC Plants
03
Industrial Automation & Utility Substation DC UPS
