The Vertiv Liebert EXS 60kVA is a high-frequency, double-conversion online three-phase uninterruptible power supply (UPS) system integrated with internal input/output breakers and a manual maintenance bypass. Engineered in a monolithic compact cabinet footprint, it supports a flexible 30-to-44 block DC bus battery architecture to deliver clean, continuous AC power for mission-critical IT edge data centers, precision healthcare equipment, and industrial automation facilities.
Pricing is confirmed by project configuration and quantity
Request a quoteThe Vertiv Liebert EXS 60kVA is a high-frequency, double-conversion online three-phase uninterruptible power supply (UPS) system integrated with internal input/output breakers and a manual maintenance bypass. Engineered in a monolithic compact cabinet footprint, it supports a flexible 30-to-44 block DC bus battery architecture to deliver clean, continuous AC power for mission-critical IT edge data centers, precision healthcare equipment, and industrial automation facilities.
The Vertiv Liebert EXS 60kVA leverages advanced IGBT double-conversion topology paired with digital signal processing (DSP) control to deliver a unity output power factor (PF=1.0, 60kVA/60kW). Delivering up to 96.5% efficiency in double-conversion mode and exceeding 99% in ECO mode, it minimizes utility power overhead and thermal dissipation in industrial switchgear rooms. The system integrates standard input, output, and maintenance bypass breakers into an optimized footprint of just 0.51 m² (600×850×1600 mm). Electrically fortified against industrial grid anomalies, the Liebert EXS supports wide input voltage and frequency tolerances, integrated surge protective devices (SPD), and selective short-circuit trip coordination. Standard RS485, CAN, dry contact ports, and intelligent slots for Web/SNMP/Modbus communication enable centralized telemetry, predictive thermal management, and reliable dual-bus synchronization for continuous operations.
The Vertiv Liebert EXS 60kVA is a high-frequency, double-conversion online three-phase uninterruptible power supply (UPS) system integrated with internal input/output breakers and a manual maintenance bypass. Engineered in a monolithic compact cabinet footprint, it supports a flexible 30-to-44 block DC bus battery architecture to deliver clean, continuous AC power for mission-critical IT edge data centers, precision healthcare equipment, and industrial automation facilities.
| Key specifications | Value |
|---|---|
| Rated Capacity kVA/kW | 60kVA / 60kW Full Active Power Online Architecture (PF=1.0) |
| Rated AC Input Voltage | 380V / 400V / 415V AC 3-Phase 4-Wire Wide Range |
| Rated AC Output Voltage | 380V / 400V / 415V AC 3-Phase Pure Sine Wave Output |
| DC Battery Bus Voltage | ±240V DC (Configurable 30~44 Lead-Acid/Lithium Cells) |
| System Comprehensive Efficiency | Up to 96.5% in Double-Conversion Mode, >99% in ECO Mode |
| Physical Form Factor | Integrated Freestanding Cabinet with Built-in Breakers & Maintenance Bypass |
| Physical Dimensions Spec | 600 × 850 × 1600 mm |
| Operating Temperature | 0°C ~ +40°C |
