HuaweiModel: Huawei TP48400C 2.1m Outdoor Power Cabinet
Huawei TP48400C 2.1m Outdoor Telecom Power Cabinet System -48V 400A IP55
Huawei TP48400C is a 2.1m high-integration outdoor integrated DC telecom power cabinet delivering -48V 400A nominal output. Featuring IP55 ingress protection and independent dual-compartment thermal regulation, it provides resilient continuous power for outdoor 5G/4G macro sites, transmission nodes, and edge telecom infrastructures.
Pricing is confirmed by project configuration and quantity
Request a quote- System Output Capacity
- 400A (-48V DC) Nominal DC Distribution Output
- Cabinet Dimensions & Type
- 2.1m Outdoor Dual-Door Integrated Enclosure (IP55 Rated)
- Rectifier Configuration
- 8 Slots (Equipped with Huawei R4850G2 50A 96% HE Rectifiers)
- Zoned Cooling Tech
- Heat Exchanger for Equipment Bay + TEC/Direct Air for Battery Bay
- Controller System
- SMU02C Controller with LCD & Centralized Remote Web/SNMP Management
- Surge Protection
- AC Class C 20kA / 40kA Surge Protective Device (SPD)
What this product is
What this product is
Huawei TP48400C is a 2.1m high-integration outdoor integrated DC telecom power cabinet delivering -48V 400A nominal output. Featuring IP55 ingress protection and independent dual-compartment thermal regulation, it provides resilient continuous power for outdoor 5G/4G macro sites, transmission nodes, and edge telecom infrastructures.
What problem it solves
The Huawei TP48400C 2.1m outdoor power cabinet unifies AC/DC power distribution, high-efficiency rectifier clusters, intelligent controller units, and internal backup battery storage. Utilizing a physical dual-compartment isolation design, the equipment compartment adopts door-mounted heat exchangers, while the battery compartment employs dedicated fan/TEC cooling. Supporting up to 8 hot-swappable Huawei R4850G2 50A 96% efficiency rectifiers alongside LLVD/BLVD protection tiers, this system ensures 24/7 durability in harsh desert, coastal, and arctic environments.
Who and where it is for
Huawei TP48400C is a 2.1m high-integration outdoor integrated DC telecom power cabinet delivering -48V 400A nominal output. Featuring IP55 ingress protection and independent dual-compartment thermal regulation, it provides resilient continuous power for outdoor 5G/4G macro sites, transmission nodes, and edge telecom infrastructures.
Core advantages
- Equipped with 8x 50A rectifiers achieving 96% peak efficiency to cut site power loss
- Industrial IP55 rated enclosure strictly shields internal parts from dust and storm
- Dual-compartment architecture with heat exchanger ensures optimal thermal zones
- Hot-swappable rectifiers support online maintenance and N+1 redundancy without downtime
- Integrated LLVD and BLVD dual-level load shedding safeguards battery bank lifespans
- SMU02C smart controller enables comprehensive SNMP/Web remote telemetries and control
Technical specifications
| Key specifications | Value |
|---|---|
| Cabinet Dimensions & Type | 2.1m Outdoor Dual-Door Integrated Enclosure (IP55 Rated) |
| System Output Capacity | 400A (-48V DC) Nominal DC Distribution Output |
| Rectifier Configuration | 8 Slots (Equipped with Huawei R4850G2 50A 96% HE Rectifiers) |
| Zoned Cooling Tech | Heat Exchanger for Equipment Bay + TEC/Direct Air for Battery Bay |
| Controller System | SMU02C Controller with LCD & Centralized Remote Web/SNMP Management |
| Surge Protection | AC Class C 20kA / 40kA Surge Protective Device (SPD) |
| Internal Battery Shelves | Supports 2 Strings of Internal 150Ah~200Ah LiFePO4 or VRLA Batteries |
| Operating Temperature | -40°C to +55°C |
Applications
01
5G/4G macro base stations and outdoor wireless transmission nodes
02
Railway signaling networks and highway surveillance telemetry relay stations
03
Remote oil, gas pipeline SCADA, and mining operation communication links
04
Edge computing facilities deployed in extreme desert and arctic environments
