Question 1

What are the core electrical specifications and surge suppression capabilities of the Huawei R1MEPF240 (HW-OLT-R1MEPF240-PWR) filter board?

Accepted Answer

The Huawei R1MEPF240 is engineered for SmartAX large-capacity chassis, operating on a nominal -48V/-60V DC input (-38.4V to -72V DC operational range). Equipped with high-current copper terminal lugs, it features a multi-stage LC low-pass filter and heavy-duty Gas Discharge Tube (GDT)/MOV array to suppress EMI and high-frequency input ripple. Designed to meet ITU-T K.20/K.45 central office standards, it provides differential-mode surge protection up to 10kV/5kA and common-mode up to 20kA. As a passive, high-conductivity board, its insertion loss is negligible, maintaining over 99.5% DC bus power efficiency under full load.

Question 2

What is the slot compatibility and dual-feed redundancy mechanism of the R1MEPF240 within SmartAX chassis?

Accepted Answer

The R1MEPF240 is natively designed for Huawei SmartAX MA5600 broadband access platforms and select large-capacity MA5680T OLT chassis, seated in the dedicated DC power input and filter slots. It supports dual-feed A+B independent -48V DC bus inputs with integrated fault isolation. Featuring keyed mechanical alignment, it is fully backward-compatible with legacy MEPF filter variants. The board incorporates reverse-polarity protection and high short-circuit withstand rating, facilitating hitless power failover between feeds to ensure zero packet drop across core control and GPON/EPON line cards during upstream power fluctuations.

Question 3

How does the R1MEPF240 perform under extreme industrial and harsh central-office environmental conditions?

Accepted Answer

The Huawei R1MEPF240 complies with carrier-class ETSI Class 4.1 standards, supporting an extended operating temperature range of -40°C to +70°C and 5% to 95% non-condensing relative humidity. Its fanless, passive design relies on conduction and natural convection cooling inside the chassis frame, eliminating mechanical point-of-failure risks. The PCB features industrial-grade conformal coating (anti-humidity, anti-salt spray, anti-fungus) with NEBS Level 3 and ETSI 300 019-2-3 seismic compliance. Rated UL 94V-0 for flame retardancy, it delivers an MTBF exceeding 500,000 hours in harsh, unconditioned outdoor cabinets.

Key specifications	Value
Board Type	High-capacity direct-current power input filtering and lightning protection board
Port Density & Specs	High-current pure-copper input terminal bar + multi-stage LC filtering and discharge tube array
Supported Chassis	Huawei SmartAX MA5600 / MA5680T large-capacity access chassis
Subscriber Capacity	High-voltage surge suppression, with lightning-current handling capacity meeting the highest rating for telecom equipment rooms
Typical Power Consumption	Fully passive, high-conductivity design with extremely low power consumption W
Operating Temperature	-40°C to +70°C
