EltekModel: Eltek Smartpack2 Master Controller (242100.501)
ELTEK Smartpack2 Master Controller (242100.501) Color TFT 18-60VDC Dual CAN Bus
The Eltek Smartpack2 Master Controller (242100.501) is an advanced telecom supervisory unit engineered for centralized administration of Flatpack2 DC power systems. Featuring a vibrant 3.2-inch TFT color touch display, it functions alongside the Smartpack2 Basic controller across redundant high-speed CAN buses to deliver real-time rectifier load balancing, sophisticated battery lifecycle testing, and carrier-grade remote SNMP/Web integration.
Pricing is confirmed by project configuration and quantity
Request a quote- Controller Positioning
- Smartpack2 flagship central controller unit with full-color touchscreen
- Display & Control Interface
- 3.2-inch 320×240 high-definition full-color TFT LCD display
- Internal Bus Interface
- Dual high-speed CAN module communication buses (supporting cascading of hundreds of modules)
- Network Management Interface
- 10/100M Ethernet port (SNMP v1/v2c/v3, Web, Modbus)
- Battery Management Features
- Advanced battery health monitoring, automated charge/discharge testing, and high-precision temperature compensation
- Operating Voltage DC
- 18V DC to 60V DC wide-range system bus power supply
What this product is
What this product is
The Eltek Smartpack2 Master Controller (242100.501) is an advanced telecom supervisory unit engineered for centralized administration of Flatpack2 DC power systems. Featuring a vibrant 3.2-inch TFT color touch display, it functions alongside the Smartpack2 Basic controller across redundant high-speed CAN buses to deliver real-time rectifier load balancing, sophisticated battery lifecycle testing, and carrier-grade remote SNMP/Web integration.
What problem it solves
The Eltek Smartpack2 Master Controller (Part No. 242100.501) represents the pinnacle of supervisory intelligence for mission-critical telecom DC microgrids and power plants. Fitted with a 3.2-inch 320x240 high-resolution TFT color display, it offers field engineers instant operational visibility, hierarchical alarm visualization, and comprehensive setting configurations directly from the front panel without requiring a dedicated service laptop. Operating across a wide 18V to 60V DC bus range, the unit employs a distributed multiprocessing architecture. It coordinates rectifiers, solar converters, and peripheral I/O units via isolated dual-CAN communication networks, ensuring high-speed telemetry and deterministic control. Advanced energy and battery management profiles feature automated discharge testing, accurate temperature compensation, cell asymmetry detection, and configurable multi-level Low Voltage Disconnect (LVD) controls. On the networking layer, an integrated 10/100M Ethernet port supports secure HTTPS, SNMP v1/v2c/v3, and Modbus-TCP, guaranteeing effortless enterprise NOC telemetry integration. The hot-pluggable chassis and an operational thermal range of -40°C to +65°C ensure uninterrupted operation in extreme ambient conditions.
Who and where it is for
The Eltek Smartpack2 Master Controller (242100.501) is an advanced telecom supervisory unit engineered for centralized administration of Flatpack2 DC power systems. Featuring a vibrant 3.2-inch TFT color touch display, it functions alongside the Smartpack2 Basic controller across redundant high-speed CAN buses to deliver real-time rectifier load balancing, sophisticated battery lifecycle testing, and carrier-grade remote SNMP/Web integration.
Core advantages
- High-definition 3.2-inch TFT color screen for intuitive on-site interaction
- Dual high-speed CAN networks for deterministic multi-rectifier synchronization
- 10/100M Ethernet with enterprise SNMP v3 and HTTPS remote management
- Advanced battery lifecycle health analysis with dynamic thermal compensation
- Hot-swappable modular form factor ensures zero downtime during maintenance
- Six user-programmable dry-contact relays for flexible local telemetry alarming
Technical specifications
| Key specifications | Value |
|---|---|
| Controller Positioning | Smartpack2 flagship central controller unit with full-color touchscreen |
| Display & Control Interface | 3.2-inch 320×240 high-definition full-color TFT LCD display |
| Internal Bus Interface | Dual high-speed CAN module communication buses (supporting cascading of hundreds of modules) |
| Network Management Interface | 10/100M Ethernet port (SNMP v1/v2c/v3, Web, Modbus) |
| Battery Management Features | Advanced battery health monitoring, automated charge/discharge testing, and high-precision temperature compensation |
| Dry Contact Alarm Outputs | 6 programmable dry contact relay alarm outputs (NO/NC selectable) |
| Operating Voltage DC | 18V DC to 60V DC wide-range system bus power supply |
| Operating Temperature | -40°C to +65°C |
Applications
01
Centralized supervisory node for 4G/5G macro and micro base station power racks
02
High-efficiency Flatpack2 DC power systems in telecom core switching facilities
03
Enterprise data center end-of-row 48V power distribution and environmental monitoring
04
Critical substation DC auxiliary power systems and railway signaling hubs
