Vertiv BMK1115601-006 Einschub-Stromversorgungsbaugruppe (-48V 200A 3U)
Kompaktes 19-Zoll-Gleichstromsystem mit weitem Wechselspannungseingangsbereich, modularer N+1 Redundanz und zweistufiger Tiefentladeschutz-Abschaltung (LLVD/BLVD).
VertivModell: MP2-220K
Vertiv MP2-220K Industrielles Stromversorgungssystem
The Vertiv MP2-220K is a microprocessor-based central supervisory controller designed for 220Vdc utility substations and critical power plants. It integrates full rectifier fleet management, busbar-to-ground insulation monitoring, dual AC source ATS automation, battery test profiling, and feeder ground fault location in a rugged industrial panel-mount enclosure.
Preise werden individuell auf Basis von Projektkonfiguration und Stückzahl kalkuliert
Angebot anfordern- Monitored DC Bus Voltage
- 220Vdc (Sampling Accuracy ±0.2%)
- Insulation Ground Fault Detection
- Busbar & Feeder Resistance Leakage Detection
- Human-Machine Interface
- Wide-Temperature Graphic LCD with Tactile Keys
- Intelligent Battery Management
- Temperature Compensated Float/Equalize & Capacity Testing
- Substation SCADA Protocols
- RS485 / IEC 60870-5-104 / CDT / Modbus-RTU
- EMC & Enclosure Standard
- Panel Flush Mount / Level 4 Industrial EMC Compliance
Produktbeschreibung
Produktbeschreibung
The Vertiv MP2-220K is a microprocessor-based central supervisory controller designed for 220Vdc utility substations and critical power plants. It integrates full rectifier fleet management, busbar-to-ground insulation monitoring, dual AC source ATS automation, battery test profiling, and feeder ground fault location in a rugged industrial panel-mount enclosure.
Problemlösung & Einsatznutzen
Resolves power grid instability, operational energy dissipation, and equipment protection challenges.
Zielgruppe und Einsatzbereich
Critical telecom facilities, data centers, utility substations, and industrial continuous power plants.
Wesentliche Vorteile
- Precision Insulation Monitoring: Combines DC bridge and low-frequency injection methods to locate feeder ground faults in milliseconds.
- Fleet Energy Optimization: Dynamically controls rectifier on/off states based on real-time load demand to maximize overall efficiency.
- Comprehensive Battery Diagnostics: Temperature compensation, Ah counting, and auto-equalizing routines maximize battery operational life.
- Substation SCADA Compatibility: Native support for IEC 60870-5-104, CDT, and Modbus-RTU protocols for seamless RTU integration.
Technische Daten
| Hauptspezifikationen | Wert |
|---|---|
| Monitored DC Bus Voltage | 220Vdc (Sampling Accuracy ±0.2%) |
| Insulation Ground Fault Detection | Busbar & Feeder Resistance Leakage Detection |
| Human-Machine Interface | Wide-Temperature Graphic LCD with Tactile Keys |
| Intelligent Battery Management | Temperature Compensated Float/Equalize & Capacity Testing |
| Substation SCADA Protocols | RS485 / IEC 60870-5-104 / CDT / Modbus-RTU |
| EMC & Enclosure Standard | Panel Flush Mount / Level 4 Industrial EMC Compliance |
Anwendungsbereiche
01
Critical Telecom Infrastructure & DC Plant
02
High-Density Cloud Computing & Enterprise Data Centers
03
Industrial Automation & Utility Substation Systems
